Measuring range:
|
-20...50°Ctd
|
|
Accuracy:
|
± 1°C at 20...-20°Ctd
± 2°C at -20...-50°Ctd
± 3°C at -50...-80°Ctd
|
|
Pressure range:
|
-1...50 bar
special version up to 350 bar
|
|
Power Supply:
|
24 VDC (16...30 VDC)
|
|
Protection class:
|
IP 65
|
|
EMC:
|
according to DIN EN 61326
|
|
Operating temp.:
|
-20...70°C
|
|
Connection:
|
M12, 5-pole
|
|
PC connection:
|
SDI interface
|
|
Analogue output:
|
4...20 mA = -80...20°Ctd resp.
4...20 mA = -20...50°Ctd
|
|
Burden for analogue output:
|
< 500 Ohm
|
|
Screw-in thread:
|
G 1/2" |
|
Dimensions:
|
Ø 30 mm, length approx. 130 mm
|
|
Via service software:
- choose units:
- scaling
|
% RH, °Ctd, g/m³, mg/m³,
ppm V/V
change 4...20 mA
|
|
Special version:
|
4...20 mA, 2-wire technology
|
