Multi-Mode: Toggle between Pit/Flaw detection (Pulse Echo Mode), and through Paint/Coatings (Echo-Echo Mode) with the single press of a button.
Alarm Mode: Enter a minimum acceptable thickness value.
If measurement falls below minimum, red led will illuminate and sound beeper. If measurement is above minimum value, green led will illuminate.
Data Ouput: RS232 output sends thickness readings to a computer or other external storage device
Pulse Echo Mode (Pit & Flaw Detection):
Measures from 0.025 to 19.999 inches (0.63 to 500 millimeters).
Echo Echo Mode (Thru Paint & Coatings):
Measures from 0.100 to 1.0 inches (2.54 to 25.4 millimeters).
Switch to select English or metric units.
Resolution: 0.001 inches (0.01 millimeters)
Velocity Range: .0492 to .3937 in/microsec (1250 to 10,000 meters/sec).
Built in: Stainless steel reference disk for probe zeroing.
Four readings per second for single point measure ments or 16 per second in scan mode — captures the minimum thickness.
Multi-function 4.5 digit liquid crystal display with 0.500 inch numerals, backlit for use in poor light conditions.
Backlight is selectable: on / off / auto ( illuminates only when taking a measurement ).
Measurements displayed in inches, inches/microsecond. millimeters, and mters/second.
Bar graph indicates stability of reading.
